Open Concept Barndominium Floor Plans, Pictures, FAQs, Tips and Much More

Interested in a Barndominium?

  • We provide lots of information about Barndominiums to help you on your journey.
  • We sell Barndominum floor plans, modify our plans and create custom house plans (for interior build out and for pricing quotes from builders).

Click here to see more than 40 Barndominium plans below.

Have questions about Barndominiums?  We have lots of answers and can help you from General Pricing and Financing options to designing your custom Barndo.

We provide floor plans for Barndominiums | Pole Barn Houses | Metal Building Homes | Metal Barn Homes.  We are here to help you understand the building process, including tips for the slab, barn, shop, and living quarters.  Some people also build their Barndo homes as a traditional stick build with 4 inch exterior walls.

Our plans show barndominium floor plans with shop but we can remove the shop if you do not want one attached.

This site will help you whether you are going to pay a company for the entire barndominium build, be your own General Contractor, or DIY Barndominium house.

How to Buy a Barndominium Floor Plan



Barndominium Floor Plans – Stock Plan Portfolio

We customize all of our plans just let us know what you would like changed.



Click Here for Plan Pricing

Why Barndominium Floor Plans?

Architectural floor plans are necessary for the planning, loan and pricing processes . Our barndo plans make it cheaper and faster to get the pricing and approval needed for your dream Barndominium home. You can also save money by starting with one of our plans and only paying for your changes versus starting from scratch (Called a Modified).

Our Barndominium plans can be used in the interior of wood pole barns, pre-engineered metal buildings, existing buildings or barns. Some people are using our plans to build their dream home but they find it cheaper to do a traditional stick build barndo like a traditional home.

Plans can be provided to contractors and banks to obtain the following:

  • Overall Barndo Building pricing
  • Bank Financing
  • Metal Building Pricing and Sizing
  • Interior Finishes
  • Building Permits, Approval
  • Septic Sizing and Permits
  • Insulation and lighting pricing (Shop Area)
  • Electrical Pricing
  • Concrete Slab Pricing
  • Plumbing Pricing
  • Framing Pricing

Our Starter and Stock architectural barndo plans are the fastest way to get started with quotes and financing. 100% of the plan cost may be applied to a Semi-Custom plan later if you decide you need to make changes. Semi-Custom and Custom floor plans allow the specification of many things including:

  • shop size
  • shop window sizes and locations
  • shop door sizes and locations
  • interior ceiling heights
  • eave height (exterior wall height)
  • roof pitch
  • vertical or horizontal siding
  • wainscot material
  • specified exterior wall thickness, column size and spacing from customer supplied building schematics

The plans below show barndo layouts only and do not include all of the information needed for pricing and construction.

Click Here for Plan Pricing

Barndominium Floor Plans


Modern Farmhouse Barndominium Plans

Our Modern Farmhouse Barndominium Plans are very popular. Some people remove the lofts while others change the layout of the loft. Other changes to the floor plans include:

  • Adding a 4th bedroom to the Version B instead of a side porch.
  • Flipping the Master Suite and Office to move the Master to the back (Version B).
  • Expanding the garage to be the same width as the home.
  • Moving the garage to the be flush with the top or bottom wall.
  • Removing the office to expand the Master Suite.
  • Expanding the Great Room by taking out the inset porch (Version A).

Modern Farmhouse A 50′ x 55′ – 3 bedroom – 2.5 bathroom (2,500 sq ft main living 23′ x 30′ shop)

modern-farmhouse-version-a-3d-rendering-with-office-plus-loft-3bed-2.5-bath-2500-sq-ft-floor-plan



Modern Farmhouse Version A Barndominium Floor Plan

Modern Farmhouse Barndominium Floor Plan Version A 3 Bedroom 2.5 Bath plus Office and Loft

Studio Barndominium Floor Plan 1 Bedroom 1 Bath Flynn
Studio Barndominium Floor Plan 1 Bedroom 1 Bath Flynn

Modern Farmhouse B 50′ x 60′ – 3 bedroom – 2 bathroom (2,810 sq ft main living 29′ x 29′ shop)

modern-farmhouse-version-b-3d-rendering-3-bed-3-bath-2810-sq-ft-floor-plan-with-office-barndominiumfloorplans

Modern Farmhouse Barndominium Floor Plan Version B 3D Rendering
Modern Farmhouse Barndominium Version B 2810 sq.ft Floor Plan

Brittany.  3 Bedroom 2.5 Bathroom 60×50 2,775 sq. ft. plus Office and Loft Plus 24×36 Shop

Brittany-3 Bedroom -2.5 Bathroom-60x50-2775-sq. ft-plus -Office-and-Loft-Plus 24x36 Shop
brittany-barndominium-loft-floor-plan-barndominiumfloorplans.com

Brittany.  60′ x 50′ – 3 Bedroom 2.5 Bathroom (2,775 sq ft.)

The Brittany Farmhouse Barndominium Floor Plan is for a 60′ wide building.  It is a modified version of our Modern Farmhouse A plan with the difference having a monitor style roof, a large, covered back porch and the interior support walls are aligned.  The barndominium with loft is a great area for entertaining and /or adding a 1-2 bedrooms to become a 4 bedroom barndominium or 5 bedroom barndominium floor plan.


Virginia 50′ x 60′ – 4 bedroom – 5.5 bathroom (4,061 sq ft living 29′ x 28′ shop)

Click here for additional versions of the Virginia plan

BarndominiumFloorPlans Virginia 4 Bedroom 5.5 Bathroom 50x60, 4,061 sq.ft with 2nd Story Loft, Balcony & Porch  plus Approx 29x28 Shop (830 sq ft)
BarndominiumFloorPlans Original Virginia Loft & Balcony
Virginia-3D-Front-Barndominium-2-Story-6050-4-Bedroom-5.5-Bath-Floor-Plan
Virginia-2D-Front-Barndominium-2-Story-6050-4-Bedroom-5.5-Bath-Floor-Plan

The Virginia Barndominium Plan with loft has 4,061 sq ft of living area.

The Virginia floor plan is a two-story with 3 bedrooms, 4.5 baths, and an office on the main level. Additionally, there is a front porch, deck, and loft with a bedroom and full bath.

*** Note most likely the Barndominium home plan will need to have a metal-framed building to have the second floor.  We do not know of wood trusses that will accommodate the second floor.
We also have versions of this plan with the living area inside a rectangle.  With the original plan, the entrance to the office is inset from the building as is the 3/4 bathroom next to the outdoor porch.

Click here for additional versions of the Virginia plan

Click Here for Plan Pricing




30-Foot-Wide Barndominium Plans


Flynn Studio 30′ x 15′ – 1 bathroom (450 sq ft living 30′ x 45′ shop)

Flynn-3dRender-leftview-Studio-plus- Bathroom-30x15- 450-sqft-plus- 30x45-Shop



Studio Barndominium Floor Plan 1 Bedroom 1 Bath Flynn

Room Sizes*
Kitchen 8’5″ X 11’4″
Great Room 13’9″ X 16’11”

Flynn Studio 30′ x 15′ -1 bathroom (450 sq ft )

The simple barndominium Flynn studio (450 sq ft) is popular for people who are building their dream shop before building their home. The studio provides living space while their home is under construction. After the home is complete, the studio can become a guest home, game room, or family room.

Click Here for Plan Pricing

General Features Room Sizes
Bathrooms 1 Full Kitchen 8'5" X 11'4"
Main Floor Residence 30' X 15' | 450 SQFT Great Room 13'9" X 16'11"
Porch N/A
Shop 30' X 45' | 1350 SQFT
Ceilings: KIT, GTR Vaulted
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 12'
Roof Pitch 4:12

Madeline 30′ x 30′ – 1 bedroom -1 bathroom (900 sq ft living 40′ x 30′ shop)

Madeline-barndo-3d-render-with-shop-1Bed-1 Bath-30x30-900- sqft



30 foot wide barndominium floor plan 1 bedroom 1 bath Madeline

Room Sizes*
Master Bedroom 13’1″ X 16’6″
Kitchen 15’4″ X 10′
Living Room 15’4″ X 17’5″

Madeline 30′ x 30′ – 1 bedroom – 1 bathroom (900 sq ft)

The shop house floor plan Madeline (900 sq ft) offers a master bedroom with a large walk-in closet. The kitchen can be customized to have an island in lieu of the breakfast bar. The shop is a convenient “drive-through”.

Click here to see the 3D Rendering of MADELINE Barndominium

Click Here for Plan Pricing

General Features Room Sizes
Bathrooms One 3/4 Master Bedroom 13'1" X 16'6"
Main Floor Residence 30' X 30' | 900 SQFT Kitchen 15'4" X 10'
Porch 25' X 10' Continuous Lean-To Living Room 15'4" X 17'5"
Shop 30' X 40' | 1200 SQFT
Ceilings: KIT, LIV Vaulted
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 12'
Roof Pitch 4:12

Lilibeth 30′ x 20′ – 1 bedroom -1 bathroom (600 sq ft living 20′ x 30′ shop)

Lilibeth-Bedroom-1-Bathroom-600-sqft-plus-20x30-Shop-3drender



600 square foot barndominium 1 bedroom 1 bath Lilibeth
 1 bedroom 1 bath Lilibeth Barndominium 3D Elevations

Room Sizes*
Master Bedroom 13’5″ X 12′
Great Room 18′ X 16′

Lilibeth 30′ x 20′- 1 bedroom -1 bathroom (600 sq ft)

The Lilibeth (600 sq ft) offers many options like compact living space or spacious guest quarters. The kitchen could be changed to a minibar to complement a fabulous game room. The bedroom could be used as an office and the family room used as a conference room.

Click Here for Plan Pricing

General Features Room Sizes
Bathrooms 1 Full Master Bedroom 13'5" X 12'
Main Floor Residence 30' X 20' | 600 SQFT Great Room 18' X 16'
Porch N/A
Shop 30' X 20' | 600 SQFT
Ceilings: GRT Vaulted
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 14'
Roof Pitch 4:12

Beatrice 30′ x 30′- 2 bedroom -1 bathroom (900 sq ft living 30′ x 30′ shop)

  Beatrice Barndominium 2 Bedroom 1 Bathroom with Kitchen Island 30 x 30 900 sq ft plus 30 x 30 Shop

900 square foot 2 bedroom 1 bath barndominium floor plan Beatrice
2 bedroom 1 bath Beatrice barndominium 3D Elevations

Room Sizes*
Master Bedroom 11’8″ X 12′
Bedroom 9′ X 12′
Kitchen 10’3″ X 15’11”
Living Room 18’11” X 15’11”

Beatrice 30′ x 30′ – 2 bedroom -1 bathroom (900 sq ft)

The Beatrice kitchen features a large center island. Customize the kitchen by moving the range or sink to the island or even add a vegetable sink. In lieu of a island, the counter top could be extended and a breakfast bar added.

Click Here for Plan Pricing


Click here to see the 3D rendering of BEATRICE Barndominium
General Features Room Sizes
Bathrooms One Full Master Bedroom 11'8" X 12'
Main Floor Residence 30' X 30' | 900 SQFT Bedroom 9' X 12'
Porch N/A Kitchen 10'3" X 15'11"
Shop 30' X 30' | 900 SQFT Living Room 18'11" X 15'11"
Ceilings: KIT, LIV Vaulted
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 12'
Roof Pitch 4:12

Ambrose 30′ x 42′ – 2 bedroom -2 bathroom (1,260 sq ft living 30′ x 28′ shop)

Ambrose-barndominium-2Bedroom-2Bath-30x42-1260-sqft-plus-30x28-Shop-3drender

1260 square foot 2 bedroom 2 bath Barndominium Floor Plan

Room Sizes*
Master Bedroom 13’10” X 14’10”
Bedroom 12’10” X 10’10”
Kitchen 11′ X 13’2″
Living Room 20’8″ X 17’2″
Mud Room 8’10” X 5’10”

Ambrose 30′ x 42′ – 2 bedroom – 2 bathroom (1,260 sq ft)

The Ambrose features a laundry/mud room and a large living room. An optional wrap around porch and sliding doors would add light and immense character.

Click Here for Plan Pricing

General Features Room Sizes
Bathrooms One Full, One 3/4 Master Bedroom 13'10" X 14'10"
Main Floor Residence 30' X 42' | 1260 SQFT Bedroom 12'10" X 10'10"
Porch N/A Kitchen 11' X 13'2"
Shop 30' X 28' | 840 SQFT Living Room 20'8" X 17'2"
Ceilings: KIT, LIV Vaulted Mud Room 8'10" X 5'10"
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 12'
Roof Pitch 4:12

Nash 30′ x 50′ – 3 bedroom -2 bathroom (1,500 sq ft living 30′ x 30′ shop)

Nash-Barndominium-3D-Rendering-3-Bed-2-Bath-1980 sq.-ft-Floor-Plan-Frontview-1



Barndominium Floor Plan 3 bedroom 2 bath 1500 square foot Nash
 3 bedroom 2 bath Nash Barndominium 3D  Elevation

Room Sizes*
Master Bedroom 15′ X 11’9″
Bedroom 10′ X 11’9″
Bedroom 10′ X 11’9″
Kitchen 11’7″ X 11’9″
Living Room 17’3″ X 16’6″
Dining Room 11’4″ X 11’9″
Laundry Room 6′ X 7′

Nash 30′ x 50′ – 3 bedroom – 2 bathroom (1,500 sq ft)

The 30×50 barndominium floor plan, Nash features an open concept great room, laundry room, and master suite. Consider adding an optional porch with sliding glass door access off the living room.

Click Here for Plan Pricing

General Features Room Sizes
Bathrooms One Full, One 3/4 Master Bedroom 15' X 11'9"
Main Floor Residence 30' X 50' | 1500 SQFT Bedroom 10' X 11'9"
Porch 10' X 24' Continuous Lean-To Bedroom 10' X 11'9"
Shop 30' X 30' | 900 SQFT Kitchen 11'7" X 11'9"
Ceilings: KIT, LIV, DIN Vaulted Living Room 17'3" X 16'6"
Ceilings: All other Rooms 8' Dining Room 11'4" X 11'9"
Ceiling: Shop Open to Above Laundry Room 6' X 7'
Eave Height 12'
Roof Pitch 4:12

Grace 30′ x 60′ -3 bedroom -2 bathroom (1,800 sq ft living 30′ x 30′ shop)

BarndominiumFloorPlans.com  Grace. 3 Bedroom 2 Bathroom 30x60 1,800 sq ft plus 30x30 Shop

BarndominiumFloorPlans.com | Grace | 3 Bedroom | 2 Bathroom | 30 Foot Wide | Barndominium Floor Plans | Pole Barn House Plans | Metal Building Homes | Metal Barn

Room Sizes*
Master Bedroom 16’1″ X 16’2″
Bedroom 10’1″ X 11’9″
Bedroom 12’1 X 11’9″
Kitchen 11’9″ X 10′
Living Room 23’7″ X 18’3″
Dining Room 11’10” X 10′
Laundry Room 6′ X 6′

Grace 30′ x 60′ – 3 bedroom – 2 bathroom (1,800 sq ft)

The shouse floor plan 3 bedroom, Grace, provides a large master suite featuring a 5-piece master bathroom. Two covered porches are included, each 8′ deep. Add panoramic patio doors to the living room to optimize your view. A pass through window providing access the back patio from the kitchen would help create the ultimate barbecue and entertaining area.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 16'1" X 16'2"
Main Floor Residence 30' X 60' | 1800 SQFT Bedroom 10'1" X 11'9"
Front Porch: 8' X 60' Continuous Lean-To Back Porch: 8' X 90' Continuous Lean-To Bedroom 12'1" X 11'9"
Shop 30' X 30' | 900 SQFT Kitchen 11'9" X 10'
Ceilings: KIT, LIV, DIN Vaulted Living Room 23'7" X 18'3"
Ceilings: All other Rooms 8' Dining Room 11'10" X 10'
Ceiling: Shop Open to Above Laundry Room 6' X 6'
Eave Height 12'
Roof Pitch 4:12

Clayton 30’x 60′- 3 bedroom -2 bathroom (1,860 sq ft living 30′ x 30′ carport)

BarndominiumFloorPlans Clayton 3 Bedroom 2 Bathroom 30x60 1,860 sq ft plus 30x30 Carport

BarndominiumFloorPlans.com | Clayton | 3 Bedroom | 2 Bathroom | 30 Foot Wide | Barndominium Floor Plans | Pole Barn House Plans | Metal Building Homes | Metal Barn

Room Sizes*
Master Bedroom 16’2″ X 16’3″
Bedroom 12′ X 11’10”
Bedroom 10′ X 11’10”
Kitchen 16’6″ X 12’3″
Living Room 23’3″ X 16’3″
Dining Room 8′ X 12’3″
Laundry Room 8’10” X 7′

Clayton 30′ x 60′ – 3 bedroom – 2 bathroom (1,860 sq ft)

The Clayton is a version of the Grace with a carport. The laundry room has been enlarged to create a mudroom connecting the carport to the living area. Additionally, the pantry and walk-in closets in the master bedroom and second bedroom have been enlarged. A sliding door has been added to the dining room, leading to a 10’x8′ back porch sized perfectly for a patio table and grill.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 16'2" X 16'3"
Main Floor Residence 30' X 60' | 1800 SQFT Bedroom 12" X 11'10"
Front Porch: 10' X 60' Roof Overhang Back Porch: 8' X 10' Roof Overhang Bedroom 10' X 11'10"
Shop 30' X 30' | 900 SQFT Kitchen 16'6" X 12'3"
Ceilings: KIT, LIV, DIN Vaulted Living Room 23'3" X 16'3"
Ceilings: All other Rooms 8' Dining Room 8' X 12'3"
Ceiling: Shop Open to Above Laundry Room 8'10" X 7'
Eave Height 12'
Roof Pitch 4:12

25-Foot-Wide Barndominium Plans


Ike 25‘x 50’- 2 bedroom – 2 bathroom (1,250 sq ft main living)

ike-barndominium-3d-elevation-perspective

barndominiumfloorplans.com - Ike-barndominium-floor-plan-2550-2BD-2BA-plus-loft

Ike 25′ x 50′ – 2 bedroom – 2 bathroom (1,250 sq ft)

The Ike Barndominium Floor Plan is a small 2 story barndominium with a 25′ wide building.  It was designed for a cabin feel with incredible window placement and is a barndominium with wrap around porch to capture views no matter where standing or sitting.  It has 2 bedrooms but the one bedroom can be an Office. The second story loft is a great place to lounge and take in views from up high. A detached shop can be an addition to this plan.



Click Here for our Plans Pricing


35-Foot-Wide Barndominium Plans


Bart 35′ x 20′ -1 bedroom -1 bathroom (700 sq ft living 35′ x 30′ shop)

bart-barndominium-3d-rendering-leftview-700-sq-ft-1bed-1bath-with-laundry-closet-plus-shop-1

35 foot wide barndominium floor plan 1 bedroom 1 bath - Bart
 1 bedroom 1 bath  Bart Barndominium 3D Elevations

Room Sizes*
Master Bedroom 15′ X 11′
Kitchen 7′ X 16′
Living Room 19′ X 16′
Laundry Room 4′ X 4′

Bart 35′ x 20′ – 1 bedroom – 1 bathroom (700 sq ft)

The small barndominium Bart plan is versatile in that it can serve as a temporary residence while a home is being constructed. It could be guest quarters or the front office for a business. Make the shop warehouse space for an online business, a vehicle repair shop, an art studio, or a hobby shop. Convert the kitchen and family room into a front office and waiting area and use the bedroom as an office or conference room. So many options!

Click Here for our Plans Pricing

Click here to see the 3D Rendering of Bart Barndominium




Beach House 35′ x 40′ – 3 bedroom -2 bathroom (1,400 sq ft living optional shop)

beach house 1400 sq ft floor plan

Beach House 35′ x 40′ – 3 bedroom – 2 bathroom (1,400 sq ft)

The Beach House plan offers three bedrooms with a master bedroom and two bathrooms.  Also, a shop can be added to this plan. This was inspired by a beach house in Galveston Texas.

Click Here for our Plans Pricing




Irene 35′ x 42′ – 2 bedroom – 2 bathroom (1,470 sq ft living 28′ x 35′ shop)

Click here to see other versions of the Irene floor plan.

barndominiumfloorplans Irene 35′ x 42′ – 2 bedroom – 2 bathroom (1,470 sq ft living 28′ x 35′ shop)

2 bedroom 2 bath Barndominium Floor plan for 35 foot wide building with a 35 x 28 shop area.

Room Sizes*
Master Bedroom 13′ X 16’5″
Bedroom 12′ X 12′
Kitchen 12′ X 12’2″
Living Room 19’1″ X 20’11”
Laundry Room 7’9″ X 9’4″

Irene 35′ x 42′ – 2 bedroom – 2 bathroom (1,470 sq ft)

Click here to see another version of the Irene here with a front hall, larger kitchen and larger master bath.

The Irene floor plan offers a convenient laundry and mud room as you enter from the shop. The master suite has a walk-in closet. Add a wraparound porch to the living room and double doors at the entry for extra character.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms One Full, One 3/4 Master Bedroom 13' X 16'5"
Main Floor Residence 35' X 42' | 1470 SQFT Bedroom 12' X 12'
Porch N/A Kitchen 12' X 12'2"
Shop 35' X 28' | 980 SQFT Living Room 19'1" X 20'11"
Ceilings: KIT, LIV Vaulted Laundry Room 7'9" X 9'4"
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 12'
Roof Pitch 4:12

Cody 35′ x 48′ – 3 bedroom – 1 bathroom (1,680 sq ft living 32′ x 35′ shop)

BarndominiumFloorPlans  Cody Barndominium-3-Bedroom-1-Bathroom-1680-sq.ft-Floor-Plan-plus-Shop

35 by 40 Barndominium floor plan 3 bedroom 1 bath - Cody
3 bedroom 1 bath  Cody Barndominium 3D Elevation

Room Sizes*
Master Bedroom 15′ X 16’5″
Bedroom 2 10′ X 12′
Bedroom 3 10′ X 12′
Kitchen 11′ X 16′
Living Room 17′ X 21′
Laundry Room 7′ X 8’6″

Cody 35′ x 48′ – 3 bedroom – 1 bathroom (1,680 sq ft)

The Cody features an open concept great room that would be ideal for a cathedral ceiling with exposed ductwork.

A spacious loft could be added above the bedrooms for storage or a bonus room. Optimize the loft space by specifying exterior wall (eave) height, roof pitch, and interior ceiling height.

Optional customizing could include replacing the washroom closets with a bench, shelves, and hooks. The large storage closet off the family room could be removed to enlarge Bedroom #3.

Click Here for our Plans Pricing

Click here to see the 3d rendering of CODY Barndominium




General Features Room Sizes
Bathrooms 1 Full Master Bedroom 15" X 16'5"
Main Floor Residence 35' X 48' | 1680 SQFT Bedroom 2 10' x 12'
Bedroom3 10' x 12'
Shop 31' X 33' | 1023SQFT Kitchen 11' X 16'
Living Room 17'6" X 21'
Ceilings: All Rooms 8' Dining Room Combined with Living
Ceiling: Shop Open to Above Laundry/Mud Room 7' X 8' 8"
Eave Height 12'
Roof Pitch 4:12

Alice 35′ x 50′ – 3 bedroom – 2 bathroom (1,750 sq ft living 35′ x 35′ shop)

Alice barndominium front porch 3 Bed 2Bath 35x50 1,750 sqft plus 35x35 Shop



alice-barndominium-floor-plan-new-final
alice-3d-elevation-perspective-front-right-back-left-barndominiumfloorplans-1750 -sq.ft

Room Sizes*
Master Bedroom 14′ X 17’4″
Bedroom 12′ X 12′
Bedroom 12′ X 12′
Kitchen 12′ X 12′
Great Room 17’4″ X 21’8″
Dining Room 11’2″ X 12′
Laundry Room 5’6″ X 7′

Alice 35′ x 50′ – 3 bedroom – 2 bathroom (1,750 sq ft)

The Alice layout is perfect for a long covered porch with dining room and master bedroom access. French doors between each room and the porch would add a lot of light.

The large master suite offers a walk-in closet, a lot of wall space, and a five-piece master bath with a water closet. Consider replacing the bathroom’s french doors with barn doors!

Click Here for our Plans Pricing

Click here to see the 3D rendering of ALICE Barndominium

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 14' X 17'4"
Main Floor Residence 35' X 50' | 1750 SQFT Bedroom 12" X 12'
Porch N/A Bedroom 12' X 12'
Shop 35' X 35' | 1225 SQFT Kitchen 12' X 12'
Ceilings: KIT, GRT, DIN Vaulted Great Room 17'4" X 21'8"
Ceilings: All other Rooms 8' Dining Room 11'2" X 12'
Ceiling: Shop Open to Above Laundry Room 5'6" X 7'
Eave Height 12'
Roof Pitch 4:12

36-Foot-Wide Barndominium Plans


Patrick 36′ x 55′ – 3 bedroom – 3 bathroom (1,980 sq ft living 25′ x 36′ shop)

Patrick-barndominium-3d-rendering-shop-1980-sq-ft-3-bed-2-bath-floor-plan-3drender

40 foot wide 2 bedroom 1 bath Barndominium Floor Plan - Autumn

Patrick 36′ x 55′ – 3 bedroom – 3 bathroom (1980 sq ft)

The Patrick is an example of a 36′ wide barndominium floor plan which is a common width for some pole barn plans and home.

Click Here for our Plans Pricing

Stella 36′ x 41′ – 3 bedroom – 3 bathroom (3,600 sq ft living 36′ x 27′ shop)

stella-barndominium-main-level-floor-plan3641-3BD-4BA-barndominiumfloorplans.com
stella-barndominium-upper-level-floor-plan-3641-3BD-4BA-barndominiumfloorplans.com
BarndominiumFloorPlans Stella-3d Elevation Perspective 3Bed-3Bathroom-36x41-3600-sq-ft-with-2nd-Story-Loft-plus-Approx-36x-27-shop-855-sq-ft

Stella 36′ x 41′ – 3 bedroom – 3 bathroom (3,600 sq ft)

The Stella Barndominium Floor Plan is for a 36′ – 2 story barndominium.  It was designed to have a traditional 2 story look with a full-length front porch and an upper and lower back porch to enjoy views from either side of the home.  An Office and open living area add to the main floor living.  The second-story loft is a great place to lounge and entertain while housing two additional bedrooms.

Click Here for our Plans Pricing


45-Foot-Wide Barndominium Plans


Ashley 45′ x 60′ – 4 bedroom – 3 bathroom (2,700 sq ft main living 45′ x 24′ Carport)

barndominiumfloorplans Ashley Barndominium Interior with playroom livingroom 45x60 2,700 sq ft floor plan

barndominiumfloorplans ashley 45x60 2,700 sq ft 4 Bed 3 Bath with playroom, office and storage room
barndominiumfloorplans 3D Elevation ashley 45x60 2,700 sq ft 4 Bed 3 Bath with playroom, office and storage room

Ashley 45′ x 60′ – 4 bedroom – 3 bathroom (2,700 sq ft)

The Ashley is a 45′ wide – 4 bedroom barndominium floor plan.  It has everything one needs on the main floor living including a Playroom, Office, KIT island,  open concept, Laundry room, Mud room, and separate storage room off of the carport.  Turn the carport into a shop or add a wrapped porch for views.

Click Here for our Plans Pricing


40-Foot-Wide Barndominium Plans


Autumn 40′ x 20′ – 2 bedroom -1 bathroom (800 sq ft living 40′ x 40′ shop)

autumn-barndominium-frontview-800-sq-ft-floor-plan-2bed-1bath-with-shop

40 foot wide 2 bedroom 1 bath Barndominium Floor Plan - Autumn

Room Sizes*
Master Bedroom 13’9″ X 11’6″
Bedroom 9’9″ X 9’6″
Kitchen 8’3″ X 14’2″
Living Room 10’11” X 14’2″
Laundry Room 5′ X 3’2″

Autumn 40′ x 20′ – 2 bedroom – 1 bathroom (800 sq ft)

The Autumn, a 40×60 barndominium, features compact living space perfect for a guest house or a luxurious “tiny house” feel. This plan is ideal for a loft, either adding a bonus room or more bedrooms and bathrooms. Endless options.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms One Full Master Bedroom 13'9" X 11'6"
Main Floor Residence 40' X 20' | 800 SQFT Bedroom 9'9" X 9'6"
Porch N/A Kitchen 8'3" X 14'2"
Shop 40' X 40' | 1600 SQFT Living Room 10'11" X 14'2"
Ceilings: KIT, LIV Vaulted Laundry Room 5' X 3'2"
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 12'
Roof Pitch 4:12

Scarlett 40′ x 30′ – 2 bedroom -2 bathroom (1,200 sq ft living 40′ x 30′ shop)



BarndominiumfloorPlans Scarlet-Barndominium-3d-rendering-1200-sq-ft-Floor-Plan-2-Bed-2-Bath-plus-Shop

40x60 barndominium floor plans with shop - Scarlett 2 Bedroom 2 Bath
 2 Bedroom 2 Bath Scarlett Barndominium 3D Elevation

Room Sizes*
Master Bedroom 12’6″ X 13’11”
Bedroom 10′ X 12′
Kitchen 11’4″ X 16’6″
Living Room 17’6″ X 19’6″
Laundry Room 5’6″ X 2’7″

Scarlett 40′ x 30′ – 2 bedroom – 2 bathroom (1,200 sq ft)

The Scarlett is a 40×60 barndominium floor plan with a shop and offers two bedrooms with walk-in closets and two full bathrooms. The laundry closet is conveniently located by the bedrooms. The layout is ideal for a loft over the bedrooms and bathrooms. A vaulted ceiling in the great room with exposed ductwork would give a modern industrial look.

We also have this plan with the Living area mirrored top to bottom and can mirror the plan left to right if you would like the garage on the other side.  If you would like to modify this plan contact us and let us know what you would like changed.

An optional front porch would warmly welcome guests.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 12'6" X 13'11"
Main Floor Residence 40' X 30' | 1200 SQFT Bedroom 10' X 12'
Porch N/A Kitchen 11'4" X 16'6"
Shop 40' X 30' | 1200 SQFT Living Room 17'6" X 19'6"
Ceilings: KIT, LIV Vaulted Laundry Room 5'6" X 2'7"
Ceilings: All other Rooms 8'
Ceiling: Shop Open to Above
Eave Height 12'
Roof Pitch 4:12

Branch 40′ x 40′- 3 bedroom – 2 bathroom (1,600 sq ft living 30′ x 40′ shop)

Click here to see other versions of the Branch floor plan.

BarndominiumFloorPlans.com | Branch | 3 Bedroom | 2 Bathroom | 40 Foot Wide | Barndominium Floor Plans | Pole Barn House Plans | Metal Building Homes | Metal Barn
3 bedroom 2 bathroom Branch Barndominium 3D Elevation

Room Sizes*
Master Bedroom 16′ X 15’4″
Bedroom 12′ X 10’2″
Bedroom 12 X 10’2″
Kitchen 11′ X 11′
Living Room 15’4″ X 20’3″
Dining Room 11′ X 12′
Pantry / Laundry Room 12’4″ X 5’6″

Branch 40′ x 40′ – 3 bedroom – 2 bathroom (1,600 sq ft)

The Branch floor plan has 1600 square feet of living space with three bedrooms and two full bathrooms. The 5-piece master bath features a luxurious two-person tub. A large combined laundry room and pantry provide great storage off the kitchen.

Click here to see other versions of the Branch floor plan.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 16' X 15'4"
Main Floor Residence 40' X 40' | 1600 SQFT Bedroom 12' X 10'2"
Porch N/A Bedroom 12' X 10'2"
Shop 40' X 30' | 1200 SQFT Kitchen 11' X 11'
Ceilings: KIT, LIV, DIN Vaulted Living Room 15'4" X 23'
Ceilings: All other Rooms 8' Dining Room 11' X 12'
Ceiling: Shop Open to Above Pantry / Laundry Room 12'4" X 5'6"
Eave Height 12'
Roof Pitch 4:12

Elaine 40′ x 40′- 3 bedroom – 2 bathroom (1,600 sq ft living 40′ x 40′ shop)

Elaine-barndominium-3Bedroom-2Bathroom-40x 40-1600sqft-plus-40x40-Shop-3drender

BarndominiumFloorPlans.com | Elaine | 3 Bedroom | 2 Bathroom | 40 Foot Wide | Barndominium Floor Plans | Pole Barn House Plans | Metal Building Homes | Metal Barn
 3 Bedroom  2 Bathroom Elaine Barndominium 3D Elevation

Room Sizes*
Master Bedroom 14’4″ X 11’6″
Bedroom 11’10” X 11’6″
Bedroom 11’10” X 11’6″
Kitchen 11′ X 16’4″
Living Room 16’8″ X 19’2″
Dining Room 11′ X 19’2″
Laundry Room 5’6″ X 5′

Elaine 40′ x 40′ – 3 bedroom – 2 bathroom (1,600 sq ft)

The Elaine a 40×80 barndominium floor plan with shop provides three bedrooms and two full bathrooms. The kitchen features a large island with seating. The pull-through shop is generously sized at 1600 square feet to house all of your toys. The front door is uniquely located on the width of the barndominium to offer an option for narrow properties. With customization, the front door may be moved to the other side of the living room.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 14'4" X 11'6"
Main Floor Residence 40' X 40' | 1600 SQFT Bedroom 11'10" X 11'6"
Porch N/A Bedroom 11'10" X 11'6"
Shop 40' X 40' | 1600 SQFT Kitchen 11' X 16'4"
Ceilings: KIT, LIV, DIN Vaulted Living Room 16'8" X 19'2"
Ceilings: All other Rooms 8' Dining Room 11' X 19'2"
Ceiling: Shop Open to Above Laundry Room 5'6" X 5'
Eave Height 14'
Roof Pitch 4:12

Levi 40′ x 50′ – 4 bedroom – 2 bathroom (2,000 sq ft living 40′ x 30′ shop)

Click here to see other versions of Levi floor plan.

barndominiumfloorplans levi barndominium 40x50 2,000 sqft floor plan 4bed 2bath plus shop
barndominiumfloorplans levi barndominium 3d elevation perspective 40x50 2,000 sqft floor plan 4bed 2bath plus shop

Room Sizes*
Master Bedroom 14′ X 15’11”
Bedroom 11′ X 13′
Bedroom 11′ X 11′
Bedroom 11′ X 11′
Kitchen 12’10” X 17’1″
Living Room 16’3″ X 22′
Laundry Room 8’4″ X 14’8″

Levi 40′ x 50′ – 4 bedroom – 2 bathroom (2,000 sq ft)

Click here to see another version of this Levi Barndominum plan.

The Levi a 40×80 barndominium floor plan with shop is a spacious 2000 square foot floor plan. The master suite has a dreamy 5-piece bathroom. The laundry/mud room could have a counter for folding laundry or a bench and hooks. The kitchen features a walk-in pantry and a giant island that could have seating or a vegetable sink or both!

The shop would be ideal for dual garage doors allowing pull-through RV, boat, or trailer storage. Customize the door sizes and locations to accommodate your usage.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 14' X 15'11"
Main Floor Residence 40' X 50' | 2000 SQFT Bedroom 11' X 13'
Porch N/A Bedroom 11' X 11'
Shop 40' X 30' | 1200 SQFT Bedroom 11' X 11'
Ceilings: KIT, LIV Vaulted Kitchen 12'10" X 17'1"
Ceilings: All other Rooms 8' Living Room 16'3" X 22'
Ceiling: Shop Open to Above Laundry Room 8'4" X 14'8"
Eave Height 12'
Roof Pitch 4:12

Jasmine 40′ x 50′ – 3 bedroom – 2 bathroom (2,000 sq ft living 40′ x 40′ shop)

Click here to see Version 2 of the Jasmine Floor Plan

Jasmine-3Bedroom-2Bathroom-40x50-2000-sqft-plus-40x40-Shop-3drender-website



40 foot wide barndominium floor plan 3 bedroom 2 bath - Jasmine
 4 bedroom 2 bath Levi Barndominium 3D Elevation

Room Sizes*
Master Bedroom 15′ X 14′
Master Bath 11’6″ X 15′
Master Closet 6′ X 6’6″
Master Shower 6′ X 5’6″
Bedroom 13’6″ X 11’6″
Bedroom 13’6″ X 11’6″
Kitchen 16’6″ X 14′
Living Room 16’6″ X 23’6″
Dining Room 16’6″ X 19′
Laundry Room 6′ X 7’6″

Jasmine 40′ x 50′ – 3 bedroom – 2 bathroom (2,000 sq ft)

Jasmine is a spacious 2000 square foot floor plan. The master suite has a 5-piece bathroom. Would you keep the large shower or have a smaller shower and larger closet?

The kitchen features a pantry and an island that could have seating along the 8′ side.

The shop is set up with dual garage doors allowing pull-through RV, boat, or trailer storage.

Would you like to change this plan? We customize all of our plans — we call them Semi-Custom – or Modified Stock Plans.

Click Here for our Barndominium Plans Pricing and Customizing Options

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 15' X 14'
Main Floor Residence 40' X 50' | 2000 SQFT Bedroom 13'6" X 11'6"'
Master Bath 11'6" X 15' Master Closet 6' X 6'6"
Porch 50' x 12' Bedroom 13'6" X 11'6"
Shop 40' X 40' | 16200 SQFT Shop Doors 3
Ceilings: KIT, DIN, LIV Vaulted Kitchen 16'6" X 14'
Ceilings: All other Rooms 10' Living Room 16'6" X 23'6"
Ceiling: Shop Open to Above Laundry Room 6' X 7'6"
Eave Height 12'
Roof Pitch 4:12

Mary 40′ x 60′ – 4 bedroom – 3 bathroom (2,400 sq ft living 36′ x 24′ garage)

BarndominiumFloorPlans Mary 40x60 2,400 sq.ft 4 Bedroom 3 Bathroom with Bonus or Office RoomPlus 36x24 Garage



barndominiumfloorplans mary barndominium 40x60 2,400 sq.ft 4 bed 3 bath plus 36xx24 garage
barndominiumfloorplans mary barndominium 40x60 2,400 sq.ft 4 bed 3 bath plus 36xx24 garage

Mary 40′ x 60′ – 4 bedroom – 3 bathroom (2,400 sq ft)

Mary is our 40×60 barndominium with shop. The home features 4 bedrooms 3 bathrooms with a generous size office.

The office can be a 5th bedroom maximizing interior space who needs the additional bedroom.

The barn home plan shows beautiful symmetrical windows to the front and back of the home with a front and back porch so a view can be enjoyed easily from either the inside or the outside of your barndominium ranch.

Click Here for our Barndominium Plans Pricing and Customizing Options


50-Foot-Wide Barndominium Plans


Randy 50′ x 40′ – 3 bedroom 2.5 bathroom (2,000 sq ft living 60′ x 50′ shop)

Randy Barndominium House Plan 50 foot wide 2,000 sq. ft.
Randy-barndominium-3d-elevation-2000-sqft-floor-plan

Randy 50′ x 40′ – 3 bedroom – 2.5 bathroom (2,050 sq ft)

The Randy a 50×100 barndominium floor plan with shop has 3 bedrooms and 21/2 baths. Two porches  and a 3,000 sq ft shop measuring 50 feet wide by 60 feet long.

Click Here for our Plans Pricing


50-Foot-Wide Barndominium Plans


Quinlan 50′ x 45′ – 4 bedroom – 2 bathroom (2,250 sq ft living 50′ x 15′ shop)

Click here to see other version of Quinlan floor plan

50 foot wide barndominium floor plan 4 bedroom 2 bath with garage - Quinlan

Room Sizes*
Master Bedroom 16′ X 16’9″
Bedroom 12′ X 12′
Bedroom 12’4″ X 12′
Bedroom 13’4″ X 10’6″
Kitchen 15’8″ X 10’8″
Living Room 20’6″ X 24′
Dining Room 15’6″ X 10′
Laundry Room 6′ X 10’6″

Quinlan 50′ x 45′ – 4 bedroom – 2 bathroom (2,250 sq ft)

Click here to see another version of this Quinlan Barndominum plan

The Quinlan is a 4 bedroom barndominium floor plan with 2 full baths. Grace the corner living room with a wraparound porch to optimize your view and add character. The utility room is tucked away in the shop/garage. The barndo plan living room could house a staircase leading up to a loft for an office, hobby room, artist studio, or library. Lofts require a taller building or a different type of truss to create the open space.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 16' X 16'9"
Main Floor Residence 50' X 45' | 2250 SQFT Bedroom 12' X 12'
Porch N/A Bedroom 12'4" X 12'
Shop 50' X 15' | 750 SQFT Bedroom 13'4" X 10'6"
Ceilings: KIT, LIV, DIN Vaulted Kitchen 15'8" X 10'8"
Ceilings: All other Rooms 8' Living Room 20'6" X 24'
Ceiling: Shop Open to Above Dining Room 15'6" X 10'
Eave Height 12' Laundry Room 6' X 10'6"
Roof Pitch 4:12

Burton Ver 4 55′ x 45′ – 3 bedroom – 2.5 bathroom (2,475 sq ft living 55′ x 45′ shop)

Click here to see other versions of the Burton floor plan

BarndominiumFloorPlans Burton V4 55x45 2,475 sq. ft. 3 Bed 2.5 Bath + Loft Option Plus 55x45 Shop

BarndominiumFloorPlans Burton V4 55x45 2,475 sq. ft. 3 Bed 2.5 Bath + Loft Option Plus 55x45 Shop
BarndominiumFloorPlans Burton V4 55x45 2,475 sq. ft. 3 Bed 2.5 Bath + Loft Option Plus 55x45 Shop
BarndominiumFloorPlans Burton V4 55x45 2,475 sq. ft. 3 Bed 2.5 Bath + Loft Option Plus 55x45 Shop

Version 4 of the Burton barndominium with shop features a Modern Layout Master Bathroom with the Master Suite dedicated to one side of the home.  Bedroom 2 and 3 share a Jack and Jill bathroom while guests have access to the 1/2 bath off of the Kitchen area.

The enclosed 2nd story to this barndo plan houses a 4th guest bedroom, a 3/4 bathroom upstairs, and a large entertainment area in the 1,127 sq ft area.

The Mudroom has an extensive amount of space for laundry and storage while the shop has pull-through OH garage doors for pulling an RV, boat, and recreational vehicles in and out of the shop.

The 3 sided barndominium with wrap around porch will make the views and entertaining enjoyable.

Hazel 50′ x 50′ – 4 bedroom – 2 bathroom (2,500 sq ft living 50′ x 30′ shop)



50 foot wide 4 bedroom Barndominium floor plan 2 bath - Hazel
4 bedroom  2 bath Hazel Barndominium 3D Elevation

Room Sizes*
Master Bedroom 14′ X 17’5″
Bedroom 11′ X 14′
Bedroom 11′ X 13’4″
Bedroom 11′ X 15’4″
Kitchen 14’9″ X 15’2″
Living Room 14’11” X 30’6″
Dining Room 14’9″ X 10’5″
Laundry Room 7’9″ X 7′
Mud Room 7’9″ X 11’7″

Hazel 50′ x 50′ – 4 bedroom – 2 bathroom (2,500 sq ft)

The Hazel floor barndominium layout is magnificently sized at 2500 square feet. The bedrooms are all generously sized. Panoramic bi-folding doors could open the dining room to the optional porch providing an amazing entertaining space.

If a half bath off the shop would be handy, please check out the Blaze floor plan which is identical but offers an additional half bath.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full Master Bedroom 14' X 17'5"
Main Floor Residence 50' X 50' | 2500 SQFT Bedroom 11' X 14'
Porch N/A Bedroom 11' X 13'4"
Shop 50' X 30' | 1500 SQFT Bedroom 11' X 15'4"
Ceilings: KIT, LIV, DIN Vaulted Kitchen 14'9" X 15'2"
Ceilings: All other Rooms 8' Living Room 14'11" X 30'6"
Ceiling: Shop Open to Above Dining Room 14'9" X 10'5"
Eave Height 12' Laundry Room 7'9" X 7'
Roof Pitch 4:12 Mud Room 7'9" X 11'7"

Blaze 50′ x 50′ – 4 bedroom – 2.5 bathroom (2,500 sq ft living 50′ x 30′ shop)

Click here to see other versions of Blaze floor plan.

Blaze-4Bedroom-2.5Bathroom-50x50-2500-sqft-plus-50x30-Shop-3drender

4 bedroom 3 bath Barndominium floor plan with garage - Blaze
4 bedroom 3 bath Barndominium floor plan with garage - Blaze

Room Sizes*
Master Bedroom 14′ X 17’5″
Bedroom 11′ X 14′
Bedroom 11′ X 13’4″
Bedroom 11′ X 15’4″
Kitchen 14’9″ X 15’2″
Living Room 14’11” X 30’6″
Dining Room 14’9″ X 10’5″
Laundry Room 7’9″ X 7′
Mud Room 7’9″ X 7’9″

Blaze 50′ x 50′ – 4 bedroom – 2.5 bathroom (2,500 sq ft)

Click here to see another version of this Blaze Barndominum plan.

The Blaze floor plan is identical to the Hazel but offers a half bath in the mudroom.

A storage loft could easily be added above the laundryroom, mudroom, and master closet and bath with stair access from the shop.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full 1 Half Master Bedroom 14' X 17'5"
Main Floor Residence 50' X 50' | 2500 SQFT Bedroom 11' X 14'
Porch N/A Bedroom 11' X 13'4"
Shop 50' X 30' | 1500 SQFT Bedroom 11' X 15'4"
Ceilings: KIT, LIV, DIN Vaulted Kitchen 14'9" X 15'2"
Ceilings: All other Rooms 8' Living Room 14'11" X 30'6"
Ceiling: Shop Open to Above Dining Room 14'9" X 10'5"
Eave Height 12' Laundry Room 7'9" X 7'
Roof Pitch 4:12 Mud Room 7'9" X 7'9"

Genevieve 50′ x 50′ – 4 bedroom – 2.5 bathroom (2,500 sq ft living 50′ x 60′ shop)

4 bedroom 3 bath Barndominium floor plan with garage - Blaze
4 bedroom 3 bath Barndominium floor plan with garage - Blaze

Genevieve 50′ x 50′ – 4 bedroom – 2.5 bathroom (2,500 sq ft)

The Genevieve 4 bedroom barndominium floor plan is an example of barndominium with a separate garage structure. In this case, the two buildings are connected. You could have a breezeway between them.

Bedroom 2 would make a nice office.

Or it could be combined with the Master Suite to have a larger master bedroom or to use the space to have a larger closet and master bathroom. This would allow you to moved Bedroom 3 down to the corner where the current closet is and moving the bathroom between the two bedrooms while enlarging them.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 2 Full 1 Half Master Bedroom 14' X 17'
Main Floor Residence 50' X 50' | 2500 SQFT Bedroom 11' X 14'
Porch N/A Bedroom 11' X 15'
Shop 58' X 48' | 3000 SQFT Bedroom 9.5' X 13'5"
Ceilings: KIT, LIV, DIN 12' Kitchen 15' X 15'
Ceilings: All other Rooms 12' Living Room 13' X 25'
Ceiling: Shop Open to Above Dining Room 13' X 11'
Eave Height 14' & 20' Laundry Room 7'9" X 7'
Roof Pitch 4:12 Mud Room 7'9" X 5'6"

Beulah 50′ x 60′ – 3 bedroom – 3 bathroom (3000 sq ft living 50′ x 40′ shop)

Click here to see the other versions of Beulah floor plan.

BarndominiumFloorPlans Beulah. 3 Bedroom 3 Bathroom + Office 50x60 3,000 sq ft plus Loft plus 50x40 Garage
4 bedroom 3 bath Beulah Barndominium 3D Elevation
beulah-barndominium-stock-floor-plan-balcony-and-loft-floor-plan

Room Sizes*
Master Bedroom 15′ X 25′
Bedroom 8′ X 14′
Bedroom 11′ X 14′
Office 11′ X 12′
Kitchen 13′ X 15′
Living Room 18′ X 26′
Dining Room 13′ X 18′
Laundry Room / Mud Room 19′ X 9′

Room Sizes*
Master Bedroom 15′ X 25′
Bedroom 8′ X 14′
Bedroom 11′ X 14′
Office 11′ X 12′
Kitchen 13′ X 15′
Living Room 18′ X 26′
Dining Room 13′ X 18′
Laundry Room / Mud Room 19′ X 9′

Beulah-3Bedroom- 3Bathroom-plus-Office-50x60 -3000-sqft-Loft-plus-50x40-Garage-3drender

Beulah 50′ x 60′ – 3 bedroom – 3 bathroom Plus Loft (3,000 sq ft)

****Click here to see the Baby Beulah and Version 2 of the Beulah Barndo plan with the Kitchen on the other side.

The Beulah plan is a 2-story barndominium with 3,000 sq. ft of living space has 3 Bedrooms and 3 Bathrooms plus an Office and a loft.

It has a 200 sq. ft. mud/laundry room.

The Master Suite has his and hers closets and a 5 piece bath.

The loft has space for another room or could be used as a rec room or media room.  The loft could be left off for a much shorter home.

For another version of the Beulah plan Click here.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 3 Full Master Bedroom 15' X 25'
Main Floor Residence 50' X 60' | 3000 SQFT Bedroom 8'6" X 14'
Porch Wrap Around Various Bedroom 8'6" X 14'
Shop 58' X 48' | 3000 SQFT Office 11' X 12'
Ceilings: KIT, LIV, DIN Vaulted Kitchen 13' X 25'
Ceilings: All other Rooms 8' Living Room 18' X 26'
Ceiling: Shop Open to Above Dining Room 13' X 18'
Eave Height 20'+ Laundry Room/Mud Room 19' X 9'
Roof Pitch 4:12

Isabella 50′ x 65′- 4 bedroom – 3 bathroom (3,250 sq ft 50′ x 35′ shop)

barndominiumfloorplans Isabella barndominium 4 bedroom 3 bath 3,250 sq ft floor plan plus 50x35 shop

50 ft wide 4 bedroom 3 bath Barndominium floor plan - Isabella
 4 bedroom 3 bath Isabella Barndominium 3D Elevation

Room Sizes*
Master Bedroom 19′ X 16’5″
Bedroom 14′ X 12′
Bedroom 14′ X 12’5″
Bedroom 14′ X 12’5″
Kitchen 14’11” X 19’5″
Living Room 19’4″ X 25’9″
Dining Room 14’11” X 12’1″
Laundry / Mud Room 14’10 X 9’9″
Bonus Room 14’10” X 19’11”

Isabella 50′ x 65′ – 4 bedroom – 3 bathroom (3,250 sq ft)

The Isabella floor plan offers 3250 square feet of living space with two covered porches that run the length of the building.

The dream master suite has its own hot water heater and his & her walk-in closets. It connects to a bonus room that can be used as a sitting room, library, or home theater.

Bedrooms 4 and 5 share a Jack & Jill bathroom with dual sinks.

Warm-up on cold winter nights with the fireplace in the living room; gas or wood, your choice.

If you’d prefer a 5th bedroom instead of a bonus room, have a look at the Wyatt.

Click Here for our Plans Pricing

Click here to see the 3D Rendering of Isabella Barndominium

General Features Room Sizes
Bathrooms Two Full One 3/4 Master Bedroom 19' X 16'5"
Main Floor Residence 50' X 65' | 3250 SQFT Bedroom 14' X 12'
Front Porch: 10' X 100' Roof Overhang Back Porch: 10' X 100' Roof Overhang Bedroom 14' X 12'5"
Shop 50' X 35' | 1750 SQFT Bedroom 14' X 12'5"
Ceilings: KIT, LIV, DIN Vaulted Kitchen 14'11" X 19'5"
Ceilings: All other Rooms 8' Living Room 19'4" X 25'9"
Ceiling: Shop Open to Above Dining Room 14'11" X 12'1"
Eave Height 12' Laundry / Mud Room 14'10" X 9'9"
Roof Pitch 4:12 Bonus Room 14'10" X 19'11"

Wyatt 50′ x 65′ – 5 bedroom – 3 bathroom (3,250 sq ft living 50′ x 35′ shop)

Wyatt-3drender-5Bedroom-3Bath- 3250-sqft-plus-50x35-Shop

5 bedroom barndominium floor plan with 3 bathrooms 50 foot wide 3,250 sq.ft.- Wyatt

Room Sizes*
Master Bedroom 19′ X 16’7″
Bedroom 15’10” X 12′
Bedroom 14’2″ X 12’2″
Bedroom 14’2″ X 12’4″
Bedroom 14’2″ X 12’7″
Kitchen 14’11” X 19’5″
Living Room 19’4″ X 25’9″
Dining Room 14’11” X 12’1″
Laundry/ Mud Room 14’10” X 9’9″

Wyatt 50′ x 65′ – 5 bedroom – 3 bathroom (3,250 sq ft)

The Wyatt 5 bedroom barndominium plan is a variation of the Isabella with 3250 square feet of living space and two covered porches, but boasts 5 bedrooms.

Another porch could be added allowing access to three bedrooms. Imagine the light French doors would add!

If you don’t require a 5th bedroom, the Isabella offers a bonus room instead. Think home theater!

Click Here for our Plans Pricing



General Features Room Sizes
Bathrooms Two Full One 3/4 Master Bedroom 19' x 16'7"
Main Floor Residence 50' X 65' | 3250 SQFT Bedroom 15'10" X 12'
Front Porch: 10' X 100' Roof Overhang Back Porch: 10' X 100' Roof Overhang Bedroom 14'2" X 12'2"
Shop 50' X 35' | 1750 SQFT Bedroom 14'2" X 12'4"
Ceilings: KIT, LIV, DIN Vaulted Bedroom 14'2" X 12'7"
Ceilings: All other Rooms 8' Kitchen 14'11" X 19'5"
Ceiling: Shop Open to Above Living Room 19'4" X 25'9"
Eave Height 12' Dining Room 14'11" X 12'1"
Roof Pitch 4:12 Laundry / Mud Room 14'10" X 9'9"

Clementine 50′ x 65′ – 5 bedroom – 3 bathroom (3,250 sq ft living 40′ x 35′ shop)

Click here to see the other versions of Clementine floor plan.

BarndominiumFloorPlans.com | Clementine| 5 Bedroom | Bathroom | 50 Foot Wide | Barndominium Floor Plans | Pole Barn House Plans | Metal Building Homes | Metal Barn
5 Bedroom  3 Bathroom Clementine 3D Elevation

Room Sizes
Master Bedroom 19′ X 16’4″
Bedroom 14′ X 11’6″
Bedroom 14′ X 11’6″
Bedroom 14′ X 12′
Kitchen 15’4″ X 19’4″
Living 19’4″ X 26’6″
Office Study 10′ X 12′
Dining 15’4″ X 12’4″
Laundry 14’4″ X 8′
Mud 14’4″ X 9’11”

Clementine-barndominium-3d-rendering-sideview-5bed-3bathroom-3250-sq.ft-plus-shop

Clementine 50′ x 65′ – 5 bedroom – 3 bathroom (3,250 sq ft)

Click here to see additional versions of the Clementine
The Clementine floor plan is another variation of the Isabella, where the living space is mirrored back to front and a hallway has been added to give access to the backyard. Additionally, the shop is sized at 40-feet wide to add geometry to this long 100-foot home.

The 10-foot wide front porch runs the entire 65-foot length topping the front French doors with a gabled entryway! Colorful rocking or Adirondack chairs would be stunning lined up across this porch!

The mudroom features a pet washing station that could be expanded to be a walk-in shower for large dogs or replaced with a laundry/hand washing sink conveniently located just inside the shop.

The large utility room houses a washer and dryer with expansive counter space.

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 3 Full Master Bedroom 19' X 16'4"
Main Floor Residence 50' X 65' | 3250 SQFT Bedroom 14' X 11'6"
Front Porch 10' X 65' Continuous Lean-To with Gabled Entry Bedroom 14' X 11'6"
Shop 40' X 35' | 1400 SQFT Bedroom 14' X 12'
Ceilings: KIT, LIV, DIN Vaulted Kitchen 15'4" X 19'4"
Ceilings: All other Rooms 10' Living Room 19'4" X 26'6"
Ceiling: Shop Open to Above Office Study 10' X 12'
Eave Height 12' Dining Room 15'4" X 12'4"
Roof Pitch 4:12 Laundry Room 14'4" X 8'

Hoyt 50′ x 66′ – 5 bedroom – 3 bathroom (3,300 sq ft living 50′ x 34′ shop)

hoyt-barndominium-3d-rendering-5-Bed–3Bath–3300-sq-ft-floor-plan-covered-porch-with-shop-1

5 bedroom Barndominium floor plan with 3 baths and shop, 3,300 sq. ft. - Hoyt

Room Sizes*
Master Bedroom 16′ X 16’5″
Bedroom 12′ X 13′
Bedroom 12′ X 13′
Bedroom 13′ X 14′
Kitchen 15’11” X 19’2″
Living Room 26’1″ X 24’2″
Office Study or Bedroom 13′ X 13’3″
Dining 15’11” X 12’5″
Laundry / Mud Room 9′ X 7’11”
Craft / Bonus Room 10′ X 9′

Hoyt 50′ x 66′ – 5 bedroom – 3 bathroom (3,300 sq ft)

The Hoyt floor plan is a variation of the Clementine where the living space is mirrored back to front and offers a 5 bedroom barndominium layout plus a craft room.

The main hallway has been widened to 6-foot wide. A stunning “dropped” lean-to porch with a gabled entryway highlights the front door with a side window.

If you would like a different style porch, we can do that with our porch design services.

Start dreaming about what you could do with that craft room. Maybe it’s another pantry, a sewing room, a playroom, or a hobby room for model trains?

Click Here for our Plans Pricing

General Features Room Sizes
Bathrooms 3 Full Master Bedroom 16' X 16'5"
Main Floor Residence 50' X 66' | 3300 SQFT Bedroom 12' X 13'
Front Porch 12' X 37'6" Dropped Lean-To with Gabled Entry Bedroom 12' X 13'
Back Porch 10' X 29'1" Dropped Lean-To Bedroom 13' X 14'
Shop 50' X 34' | 1700 SQFT Kitchen 15'11" X 19'2"
Ceilings: KIT, LIV, DIN Vaulted Living Room 26'1" X 24'2"
Ceilings: All other Rooms 8' Office Study or Bedroom 13' X 13'3"
Ceiling: Shop Open to Above Dining Room 15'11" X 12'5"
Eave Height 12' Laundry / Mud Room 9' X 7'11"
Roof Pitch 4:12 Craft / Bonus Room 10' X 9'

*Room sizes are approximate
